Technical data
Area: Ø 0,90 m
Minimum space: Ø 4,90 m (19 m²)
Height: 1,05 m
Weight: 55 kg heaviest single component
60 kg as a whole
Rotating bowl and structure: stainless steel
Roller bearing: tamper-proof and dirt-protected
Anchorage by means of concreted foundation ring made from galvanised steel
Foundation (on site)
1 pc. 0,35 x 0,35 x 0,60 m
concrete amount: 0,13 m³
Approximate assembly values
1 mechanic 1 hours each
(without creating foundations)
Free height of fall
0,45 m
Please note
Beneath all playground equipment causing a forced movement on the body of the user (e.g. swings, slides, rocking equipment, cableways, carousels etc.), there shall be impact attenuating surfacing over the entire impact area.
Appropriate for
children from the age of 3 years up,
public playgrounds etc.,
physical activity
