Technical data
Area: Ø 0,40 m
Minimum space: Ø 3,40 m (9 m²)
Height: 1,15 m
Weight: 40 kg heaviest single component
45 kg as a whole
– rotating bowl and structure: stainless steel
– tamper-proof, dirt-protected roller bearing
– ring-shaped flange anchorage
Foundation (on site)
1 pcs. 0,50 x 0,50 x 0,50 m
concrete amount: 0,13 m³
Approximate assembly values
1 mechanic 1 hours each
(without creating foundations)
Free height of fall
0,60 m
Please note
Beneath all playground equipment causing a forced movement on the body of the user (e.g. swings, slides, rocking equipment, cableways, carousels etc.), there shall be impact attenuating surfacing over the entire impact area.
Appropriate for
children from the age of 3 years up,
public playgrounds etc.,
physical activity
